DATA SHEET
GaAs MULTI-CHIP MODULE
MC-7831
870 MHz CATV 18 dB PUSH-PULL AMPLIFIER
DESCRIPTION
The MC-7831 is a GaAs Multi-chip Module designed for use in CATV applications up to 870 MHz. This unit has
low distortion, low noise figure and return loss across the entire frequency band.
Reliability and performance uniformity are assured by our stringent quality and control procedures.
FEATURES
? Low distortion
? High linear gain
G L = 18.0 dB MIN. @f = 870 MHz
? Low return loss
ORDERING INFORMATION
Part Number
Order Number
Package
Supplying Form
<R>
MC-7831
MC-7831-AZ
7-pin special with heatsink
25 pcs MAX./Tray
(Pb-Free)
Remark To order evaluation samples, contact your nearby sales office.
Part number for sample order: MC-7831-AZ
ABSOLUTE MAXIMUM RATINGS (T A = +25 ? C)
Parameter
Supply Voltage
Symbol
V DD
Ratings
30
Unit
V
Input Voltage
Note
V i
65.0
dBmV
Operating Case Temperature
Storage Temperature
T C
T stg
? 30 to +100
? 40 to +100
? C
? C
Note In case of single tone
Caution : Observe precautions when handling because these devices are sensitive to electrostatic discharge
Document No. PG10090EJ04V0DS (4th edition)
Date Published December 2006 NS CP(N)
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
